[SOLVED] TLS 1.2 – SSLHandshakeException: Remote host closed connection during handshake

SSLHandshakeException appear in logs when there is some error occur while validating the certificate installed in client machine with certificate on server machine. In this post, we will learn about fixing this if you are using Apache HttpClient library to create HttpClient to connect to SSL/TLS secured URLs.

The exception logs will look like this.

Caused by: javax.net.ssl.SSLHandshakeException: Remote host closed connection during handshake
	at sun.security.ssl.SSLSocketImpl.readRecord(SSLSocketImpl.java:980)
	at sun.security.ssl.SSLSocketImpl.performInitialHandshake(SSLSocketImpl.java:1363)
	at sun.security.ssl.SSLSocketImpl.startHandshake(SSLSocketImpl.java:1391)
	at sun.security.ssl.SSLSocketImpl.startHandshake(SSLSocketImpl.java:1375)
	at org.apache.http.conn.ssl.SSLConnectionSocketFactory.createLayeredSocket(SSLConnectionSocketFactory.java:275)
	at org.apache.http.conn.ssl.SSLConnectionSocketFactory.connectSocket(SSLConnectionSocketFactory.java:254)
	at org.apache.http.impl.conn.HttpClientConnectionOperator.connect(HttpClientConnectionOperator.java:117)
	at org.apache.http.impl.conn.PoolingHttpClientConnectionManager.connect(PoolingHttpClientConnectionManager.java:314)
	at org.apache.http.impl.execchain.MainClientExec.establishRoute(MainClientExec.java:363)
	at org.apache.http.impl.execchain.MainClientExec.execute(MainClientExec.java:219)
	at org.apache.http.impl.execchain.ProtocolExec.execute(ProtocolExec.java:195)
	at org.apache.http.impl.execchain.RetryExec.execute(RetryExec.java:86)
	at org.apache.http.impl.execchain.RedirectExec.execute(RedirectExec.java:108)
	at org.apache.http.impl.client.InternalHttpClient.doExecute(InternalHttpClient.java:186)
	at org.apache.http.impl.client.CloseableHttpClient.execute(CloseableHttpClient.java:82)
	at org.apache.http.impl.client.CloseableHttpClient.execute(CloseableHttpClient.java:57)
	at org.springframework.http.client.HttpComponentsClientHttpRequest.executeInternal(HttpComponentsClientHttpRequest.java:88)
	at org.springframework.http.client.AbstractBufferingClientHttpRequest.executeInternal(AbstractBufferingClientHttpRequest.java:46)
	at org.springframework.http.client.AbstractClientHttpRequest.execute(AbstractClientHttpRequest.java:49)
	at org.springframework.web.client.RestTemplate.doExecute(RestTemplate.java:509)
	... 61 more
Caused by: java.io.EOFException: SSL peer shut down incorrectly
	at sun.security.ssl.InputRecord.read(InputRecord.java:505)
	at sun.security.ssl.SSLSocketImpl.readRecord(SSLSocketImpl.java:961)
	... 80 more

I have already posted code fix to bypass SSL matching in earlier post.

Unfortunately, that fix works in TLS and TLS 1.1 protocols. It doesn’t work in TLS 1.2 protocol. So ultimately, you need to fix the certificate issue anyway. There is ‘no code only’ fix for this.

Now there are two ways, you can utilize the imported certificate from server. Either add certificate to the JDK cacerts store; or pass certificate information in JVM aruguments.

1) Import certificate to JDK cacert store

  1. Import the certificate from server.
  2. Use given command to add the certificate to JDK store. (Remove new line characters).
    keytool -import
    	-noprompt
    	-trustcacerts
    	-alias MAVEN-ROOT
    	-file C:/Users/Lokesh/keys/cert/maven.cer
    	-keystore "C:/Program Files (x86)/Java/jdk8/jre/lib/security/cacerts"
    	-storepass changeit


Now create HTTP client as given:

public HttpClient createTlsV2HttpClient() throws KeyManagementException,
				UnrecoverableKeyException, NoSuchAlgorithmException, KeyStoreException {

      SSLContext sslContext = SSLContext.getInstance("TLSv1.2");

      SSLConnectionSocketFactory f = new SSLConnectionSocketFactory(sslContext, new String[] { "TLSv1.2" }, null,
                   						SSLConnectionSocketFactory.ALLOW_ALL_HOSTNAME_VERIFIER);

      Registry<ConnectionSocketFactory> socketFactoryRegistry = RegistryBuilder.<ConnectionSocketFactory>create()
                   		.register("http", PlainConnectionSocketFactory.getSocketFactory())
                   		.register("https", f)
                   		.build();

      PoolingHttpClientConnectionManager cm = new PoolingHttpClientConnectionManager(socketFactoryRegistry);

      CloseableHttpClient client = HttpClients
      					.custom()
      					.setSSLSocketFactory(f)
                   		.setConnectionManager(cm)
                   		.build();
      return client;
}

Notice the code : SSLContext.getInstance("TLSv1.2"). This code picks up the certificates added to JDK cacert store. So make a note of it.

2) Pass certificate information in JVM aruguments

  1. Import the certicate from server.
  2. Add JVM arguments while starting the server. Change the parameter values as per your application.
    -Djavax.net.ssl.keyStore="C:/Users/Lokesh\keys\maven.jks"
    -Djavax.net.ssl.keyStorePassword="test"
    -Djavax.net.ssl.trustStore="C:/Users/Lokesh\keys\maven.jks"
    -Djavax.net.ssl.trustStorePassword="test"


Now create HTTP client as given:

public HttpClient createTlsV2HttpClient() throws KeyManagementException,
				UnrecoverableKeyException, NoSuchAlgorithmException, KeyStoreException {

      SSLContext sslContext = SSLContexts.createSystemDefault();

      SSLConnectionSocketFactory f = new SSLConnectionSocketFactory(sslContext, new String[] { "TLSv1.2" }, null,
                   						SSLConnectionSocketFactory.ALLOW_ALL_HOSTNAME_VERIFIER);

      Registry<ConnectionSocketFactory> socketFactoryRegistry = RegistryBuilder.<ConnectionSocketFactory>create()
                   		.register("http", PlainConnectionSocketFactory.getSocketFactory())
                   		.register("https", f)
                   		.build();

      PoolingHttpClientConnectionManager cm = new PoolingHttpClientConnectionManager(socketFactoryRegistry);

      CloseableHttpClient client = HttpClients
      					.custom()
      					.setSSLSocketFactory(f)
                   		.setConnectionManager(cm)
                   		.build();
      return client;
}

Notice the code : SSLContext.createSystemDefault(). This code picks up the certificates passed as JVM arguments. Again, make a note of it.

Summary

  1. Use SSLContext.getInstance("TLSv1.2") when certificate is added to JDK cacert store.
  2. Use SSLContext.createSystemDefault() when SSL info is passed as JVM argument.

Drop me your questions in comments section.

Happy Learning !!

Was this post helpful?

Join 7000+ Fellow Programmers

Subscribe to get new post notifications, industry updates, best practices, and much more. Directly into your inbox, for free.

3 thoughts on “[SOLVED] TLS 1.2 – SSLHandshakeException: Remote host closed connection during handshake”

  1. Hello Lokesh,

    Thanks for posting this article.

    I have the same issue while redeploying JEE application on Payara5. Could you please advise – I assume that the certificate (.crt) file that need to go into the JKS store is the .crt for the domain. I am bit confused that you have specified “maven.cer” file!

    Reply
  2. Hi Lokesh,

    I am using rest assured to connect to external api- which is twilio. I have added twilio certs to location /Java/jdk8/jre/lib/security/cacerts. I am still getting ssl hand shake error.

    javax.net.ssl.SSLHandshakeException: Remote host closed connection during handshake
    Caused by: java.io.EOFException: SSL peer shut down incorrectly

    Can you help?

    Reply
